Teldor Cable
8MG1347109
Call for Price
RFOU (I) 1PR 2.5
Armoring
Braided Tinned Copper
Armor Coverage min.
90%
Weight
235 kg/km
Voltage Rating
150/250 (300) V
Overall Shield Material
Copper/Polyester Foil
Overall Shield Design
100% Coverage
Overall Drain-wire size
16 AWG
Overall Drain-wire Material
Annealed Tinned Copper
Outer Jacket Thickness
1.2 mm nom.
Outer Jacket Material
XL-HFFR
Outer Jacket Color
Gray
Outer Diameter
12.0 mm nom.
Minimum Operating Temperature
-40°C
Min. Bend Radius
D x 10
Maximum Operating Temperature
+85°C
Max. DC Resistance
7.56 Ω/km@20°C
Insulation Thickness
0.6 mm
Insulation O.D.
3.3 mm nom.
Insulation Material
XLPE
Inner Jacket Thickness
1.1 mm nom.
Inner Jacket Material
FR-LSZH
Inner Jacket Diameter
8.8 mm nom
Inner Jacket Color
Gray
Dielectric Strength to Shield
1000 V/minute
Dielectric Strength
1500 V/minute
Conductor Material
Annealed Tinned Copper
Conductor Cross Section
2.5 mm²
Conductor Construction
7 x 0.68 mm
Conductor Color Code
Black x Blue
